Operation:
- Press Switch on front to turn on and change modes
- If pressing switch does not do anything connect charger for a couple hours
- Keep sensor cavity clean, clean gently with alchohol and Q-tip if necessary
- Press Switch to cycle between modes:
- Meter Peak Hold, holds the highest UVA UVB and UVC reading
- Live meter display UVA UVB and UVC readings
- Oscilloscope Slow UVA only
- Oscilloscope Slow UVB only
- Oscilloscope Slow UVC only
- Oscilloscope Fast UVA only
- Oscilloscope Fast UVB only
- Oscilloscope Fast UVC only
- Hold down the Switch for 3 seconds to turn off tester
- Tester will automatically turn off if battery voltage gets too low
- Recharge unit every 6months to extend battery life
Demo Video using UV11:
|
|
